H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder

H2W

$3518.73 - $11343.78

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1

$3518.73 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1PRO

$4930.03 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1+R2

$5474.99 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1PRO+R2

$6886.30 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1+2XR2

$7431.26 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1PRO+2XR2

$8842.56 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1+3XR2

$7976.21 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1PRO+3XR2

$9387.52 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-W1PRO+4XR2

$11343.78 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-R2

$4063.69 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-2XR2

$6019.95 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-3XR3

$7976.21 (Out Of Stock)

H2W hybrid off-on grid 4.5kWh inverter 5kW allinone preorder - H2W-3XR3

$7976.21 (Out Of Stock)

All-in-one solar battery, which integrates inverter and solar energy storage and means storage of charging energy and AC sine wave output. Thanks to DSP control and advanced control algorithm, it has high response speed, high reliability, and high industrial standards. Four charging modes are optional: Solar Only, Grid Priority, Solar Priority, and Hybrid Grid and Solar Charging; and two output modes are available, namely Inverter and Grid, to meet different application requirements. Stable AC sine wave output via SPWM modulation Supports a wide range of battery technologies: sodium ion. Dual SIB battery activation method: PV and grid power supply Uninterrupted power supply: simultaneous connection to grid/generator and PV. Intelligent programming: it is possible to set the output priority from different energy sources. High energy efficiency: MPPT capture efficiency up to 98%. Instant operation display: the LCD panel displays data and settings, while it is also possible to view them via app and web page. Energy saving: the energy saving mode automatically reduces energy consumption at zero load. Efficient heat dissipation: via intelligent variable speed fans Multiple safety protection functions: short circuit protection, overload protection, reverse polarity protection, and so on. Undervoltage and overvoltage protection and reverse polarity protection. Supports up to 4 devices of the same model connected in parallel (forming a single-phase, two-phase, or three-phase electrical system) For single-phase configuration, the system is expandable up to 18kW and 72kWh and for three-phase configuration, you need to connect 3 units forming a 15kW and 54kWh battery system ready for any situation and it is possible to reach 4*3 units at 60kW and 216kWh of storage for commercial and public systems. In the Google Play Store and Apple App Store, to monitor consumption Battery specifications with inverter

Model	H2W-W1	H2W-W1 Pro
Connection	OFF-GRID Island
Battery type	Sodium ion
Capacity	4.5kWh	4.5kWh
Life cycle (25 2 C, 0.5C/0.5C, 80% DOD)	5,000
Nominal battery voltage	45V
Max. Continuous charge/discharge current	1C/1C
Input (PV)
Max. DC Power	5,000W	7,500W
Max. DC input voltage	450V	600V
MPPT voltage range	120V ~ 400V	80V ~ 550V
MPPTs	1	2
OFF-Grid Output (AC)
Nominal apparent power	5KW	5kW
Max. Output current	21.7A	22.7A
Nominal output voltage	230 Vac	220 / 230 / 240 Vac
Power factor	O.8leading - 0.8 lagging
Efficiency
Maximum efficiency	97%	98%
Control and monitoring platform
Human-machine interaction	LCD	APP
Firmware update mode	Local update	FOTA/local update
Operation and maintenance model	Local O & M	Remote O & M / Local O & M
General parameters
Grid type	Single-phase	Remote 08M/local O & M
Operating temperature	Charge: -20 C ~ + 55 C (-4 F ~ 131 F), discharge:-30 C ~ 55 C (-22 F ~ 131 F)
Operating humidity	5% RH ~ 95% RH
Max. Operating altitude	4,000 m (13,123 ft.) derating above 2,000m
Cooling mode	Forced air cooling	Intelligent air cooling
BMS communication mode	RS485 / CAN
Weight	85 kg	113 kg
Size (W x H x D	600 880 165mm (23.6 34.6 6.5 in)	670 1,060 210mm (26.4x41.7x8.3 in)
Enclosure IP rating	IP21	IP65
Installation method	Wall mount/floor mount
General parameters
CE_LVD	EN 62619, EN 62109-1/-2
CE_EMC	EN IEC 61000-6-1, EN IEC 61000-6-3, EN IEC 61000-6-2, EN IEC 61000-6-4
